2MP Vandal Dome IP Camera
2MP, 2.8-12mm, 30M IR
IP66, IP68, IK10
FEATURES
SPECIFICATION
DIMENSION
DOWNLOAD
FEATURES
SPECIFICATION
Product Name | H.264+ 2MP IR Vandal Dome |
| Model | HLV-1WKD |
| Maximum Resolution | 1920×1080 (2MP) |
| Sensor | 1/2.9″ CMOS Sensor |
| Lens | 2.8-12 mm Varifocal Lens @ F1.4 |
| Sensitivity | Color: 0.05Lux (AGC ON), B/W: 0.01Lux (AGC ON) |
| FOV | 34° – 100° (H), 19° – 52° (V) |
| IR Distance | 4xHigh Power LEDs, 850nm, IR Distance 30M |
| Video Format | H.264+ / H.264 / MJPEG |
| Video Resolution | 1920×1080@30fps, 1280×720@30fps 640×360 @30fps |
| Maximum Streams | 4 Simultaneous Streams |
| Audio Format | G.711 (64K) / G.726 (32K, 24K) |
| Audio | Input: Ø3.5mm stereo jack, Output: Ø3.5mm stereo jack Support 2 way audio |
| Interface | DIX1, DOx1, Micro SD card slot (Optional), 3 Axis bracket, BNC output, RJ45 |
| Network Protocol | IPv6, IPv4, HTTP, HTTPS, SNMP, SSL, TLS, DNS, ICMP, IGMP, ARP, SNTP, QoS/DSCP, COS, IEEE 802.1X, RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, Network Protocol PPPOE, DHCP, DDNS, NTP, UPnP, SAMBA, Bonjour, Google Drive, Dropbox, ONVIF Profile S |
| Power Comsumption | DC 12V Max: 5.0W, POE Max: 6.3W |
| Intelligent Feature | ROI, Smart Stream, Motion Detection, Privacy Mask, Defog, Lens Distortion Correction (LDC), Corridor Mode, Tampering Detection, Sound Detection, 3D DNR, Smart IR, P2P (optional), Seamless Recording, Off-site and Cloud Backup, Automatic Network Replenishment (ANR) Push Video Notification, Advanced Smart Stream |
| Dimensions | Ø137 x H102 (mm) |
| Weight | 890 g |
| Working Temparature | -20° C~60° C / -4° F~140° F |
DIMENSION
DOWNLOAD
