Traffic Box IP Camera
2MP, CS Mount, 60FPS, 1/2″ sensor
Super T-WDR, DIS, LPR, -20℃~70℃
FEATURES
SPECIFICATION
DIMENSION
DOWNLOAD
FEATURES
SPECIFICATION
| Product Name | H.264+ 2MP Super Starvis Box Camera |
| Model | HLC-81KDP |
| Maximum Resolution | 1920×1080 (2MP) |
| Sensor | 1/2″ Sony Starvis CMOS Sensor |
| Lens | CS mount |
| Sensitivity | Color: 0.001Lux (AGC ON), B/W: 0.0005 Lux (AGC ON) |
| Video Format | H.264+ / H.264 / MJPEG |
| Video Resolution | 1920×1080@60fps, 1920×1080@30fps, 1280×720@30fps, 640×360@30fps |
| Maximum Streams | 4 Simultaneous Streams |
| Audio Format | G.711 (64K) / G.726 (32K, 24K) |
| Audio | Input: Ø3.5mm stereo jack, Output: Ø3.5mm stereo jack, Support 2 way audio |
| Interface | Dix1, DOx1, SD card slot (Optional), WiFi (Optional), BNC output, RS485, RJ45 |
| Network Protocol | IPv6, IPv4, HTTP, HTTPS, SNMP, SSL, TLS, DNS, ICMP, IGMP, ARP, SNTP, QoS/DSCP, COS, IEEE 802.1X, RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, PPPOE, DHCP, DDNS, NTP, UPnP, SAMBA, Bonjour, Google drive, Drop box, Onvif profile s |
| Power Comsumption | DC 12V Max: 2.26W, PoE Max: 3.32W |
| Intelligent Feature | ROI, Smart Stream, Advanced Smart Stream, Motion Detection, DIS,Privacy Mask, Defog, Lens Distortion Correction (LDC), Corridor Mode, Tampering Detection, Sound Detection, 3D DNR, P2P (Optional), SeamlessRecording, Off-site and Cloud Backup, Automatic Network Replenishment (ANR), Push Video Notification |
| Dimensions | W65 x H58 x L132 (mm) (without lens) |
| Weight | 450 g (without lens) |
| Working Temparature | -20° C~70° C / -4°F~158° F |
