Product Name | H.264+ 4MP Mini IR Bullet |
Model | HLC-75KQ |
Maximum Resolution | 2592×1520 (4MP) |
Sensor | 1/3″ CMOS Sensor |
Lens | 3.6 mm @ 2.0 |
Sensitivity | Color: 0.08Lux (AGC ON), B/W: 0.03Lux (AGC ON) |
FOV | 77.5° (H), 44.7° (V) |
IR Distance | 6 x High Power LEDs, IR Distance 30M” |
Video Format | H.264/MJPEG |
Video Resolution | 2592×1520@25fps, 1920×1080@30fps, 1280×720@30fps,640×360@30fps |
Maximum Streams | 4 Simultaneous Streams |
Interface | Micro SD card slot (Optional), 3 Axis management bracket, |
Network Protocol | IPv6, SNMP, SSL, TLS, DNS, ICMP, IGMP, ARP, SNTP, QoS/DSCP, |
Power Comsumption | DC 12V Max: 4.5W, PoE Max: 6.5W |
Intelligent Feature | ROI, Smart Stream, Corridor Mode, Tampering Detection, Sound |
Dimensions | Ø68xH102 (mm) |
Weight | 550g |
| Working Temparature | -20° C~60° C/ -4° F~140° F |
