Product Name

H.264 2MP Mini IR Bullet

Model

HLC-74MD

Maximum Resolution

1920×1080 (2MP)

Sensor

1/2.7″ CMOS Sensor

 Lens

3.6mm @ F2.0,

Sensitivity

Color: 0.1 Lux(AGC ON), B/W: 0.05Lux(AGC ON)

FOV

86° (H), 45° (V)

IR Distance

6 x High Power LEDs, IR Distance 30M

Video Format

H.264/M-JPEG

Video Format

1920×1080@30fps, 1280×720@30fps, 640×480@30fps, 320×240@30fps, 176×144@30fps

Maximum Streams

2 Simultaneous Streams

Audio Format

G.711 (64K) / G.726 (32K, 24K)

Audio

Input: Ø3.5mm stereo jack, Output: Ø3.5mm stereo jack, Support 2 way audio

Interface

DIx1, DOx1, Micro SD card slot (Optional), 3 Axis management bracket, RJ45

Network Protocol

HTTP, HTTPS, IPv4, RTSP/RTP/RTCP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP, SAMBA, Bonjour, Google Drive, Dropbox, ONVIF Profile S

Power Comsumption

DC 12V Max: 4.3W, PoE Max: 5.1W

Intelligent Feature

Motion Detection, Privacy Mask, Defog, Lens Distortion Correction (LDC), 3D DNR, P2P (Optional), Seamless Recording, Off-site and Cloud Backup, Push Video

Dimensions

068 x H101.5 (mm)

Weight

480g

-10° (~60° C / -4° F~140° F
